AuW195 i country four cold milling machine
AuW195 i country four cold milling machine
| AuW195 i country four cold milling machine | Wirtgen W 195 i country four cold milling machine technical parameters | |||||||
| Technical specifications: | Model: | W 195i cold milling machine | ||||||
| Manufacturer/Model | Cummins/QSX15 | engine | East Wind - Cummins X15 | |||||
| Fine model | 447 kW/600 HP@2100 rpm | Rated power, 2,200 RPM | 373 kW / 500 hp / 507 PS | |||||
| Efficient mode | 455 kW/610 HP@1900 rpm | Milling width | 2,000 mm | |||||
| Economic model | 430 kW/577 HP@1700 rpm | Milling depth | 0-330 mm | |||||
| engine | Let out | State stage 3 | Fuel tank | 1,160 l | ||||
| Milling width (mm) | 2000 | Water tank | 3,280 l | |||||
| Milling depth (cm) | 0～33 | Milling speed | 0-85 m/min | |||||
| Edge milling depth (cm) | 0 ～ 45 | Travel speed | 5 km/h | |||||
| Milling rotor diameter (mm) | 1070 | Emission standard | Kokuni IV | |||||
| Milled rotor | Rotor cutter spacing (mm) | 18 | ||||||
| Fuel Tank (L) | 1130 | |||||||
| Hydraulic Tank (L) | 220 | |||||||
| Box volume | Water tank (L) | 3000 | ||||||
| Travel speed (m/min) | 0 ～ 85 | |||||||
| Driving performance | Minimum milling turning radius (m) | 2 | ||||||
| Track assembly | Track, front and rear ( | 1850×300×665 | ||||||
| Length × width × height)(mm) | ||||||||
| Receiving belt width (mm) | 850 | |||||||
| Feed conveyor swing Angle (°) | 120 | |||||||
| Theoretical capacity (m /h) | 385 | |||||||
| Material handling system | Feed height (mm) | 4900 | ||||||
| Shipping weight (t) | 31.5 | |||||||
| Working weight (t) | 33.5 | |||||||
| Maximum weight (t) | 35.5 | |||||||
| weight | Removable configuration (optional) (t) | 1.5 |
